Technical
Specification
| Cooling Features : | |||
|---|---|---|---|
| Type | Direct Cool | ||
| Capacity : | |||
| Gross Volume | 312 Ltr. | ||
| Net Volume | 290 Ltr. | ||
| Net Weight | 65 ± 2 Kg | ||
| Gross Weight | 72 ± 2 Kg | ||
| Performance : | |||
| Climate Type (SN, N, ST, T) | N ~ ST | ||
| Rated Operating Voltage and Frequency | 220-240V~ and 50Hz | ||
| Compressor Input Power (Watt) | V 0101 -145.7 V 0201 - 145.7 V 0301 - 117 V 0302 - 117 V 0501 - 123 | ||
| Compressor Type | V 0101 - RSIR V 0201 - RSIR V 0301 - RSIR V 0302 - RSIR V 0501 - RSIR | ||
| Cooling Efect | Freezer Cabinet Less than -18 ̊C Refrigerator Cabinet 0 ̊C to +5 ̊C | ||
| General features : | |||
| Temperature Control (Electronic/ Mechanical) | V 0201 - Mechanical V 0301 - Mechanical V 0302 - Mechanical V 0501 - Mechanical | ||
| Defrosting (Automatic/ Manual) | Manual | ||
| Reversible Door | No | ||
| Handle (Recessed/ Grip) | Recressed/ Grip/ Built-in | ||
| Lock | Yes | ||
| Refrigerant | V 0101 - R600a V 0201 - R600a V 0301 - R600a V 0302 - R600a V 0501 - R600a | ||
| Capillary | Copper | ||
| Thermostat | RoHS Certified | ||
| Polyurethane foam blowing agent | CycloPentene [Eco-friendly (100% CFC & HCFC Free) Green Technology] | ||
| Recommended voltage stabilizer capacity | V 0201/0202/0203/0301: Wide Voltage Design (145V-253V) N.B.: If out of voltage range (145V-253V) then suggested voltage stabilizer capacity is 2100VA. V 0501:Wide Voltage Design (75V-264V) N.B.: If out of voltage range(75V-264V) then suggested voltage stabilizer capacity is 2100VA. | ||
| Refrigerator Compartment : | |||
| Shelf (Material/ No.) | Wire/2 | ||
| Door Basket | PVC/3 | ||
| Interior Lamp | Yes | ||
| Vegetable Crisper | Yes (Plastic) | ||
| Vegetable Crisper Cover | Yes (ABS/ PS) | ||
| Egg Tray or Pocket | Yes | ||
| Can Storage Dispenser | No | ||
| Deodorizer | No | ||
| Freezer Compartment : | |||
| Shelf (Material/ No.) | Wire/2 | ||
| Drawer | No | ||
| Door Basket | No | ||
| Interior Lamp | No | ||
| Net Dimensions : | |||
| Width/mm | 594 | ||
| Depth/mm | 708 | ||
| Height/mm | 1620 | ||
| Packaging Dimensions : | |||
| Width/mm | 635 | ||
| Depth/mm | 740 | ||
| Height/mm | 1690 | ||
| Loading Capacity- 40HQ/ 40Ft/ 20Ft | 78/ 57/ 27 | ||
