Download Refrigerator User Manual Summary
Note:
| Type | Direct Cool |
| Capacity : | |
Gross Volume | 177 Ltr. |
Net Volume | 175 Ltr. |
| Net Weight | 50 ± 2 Kg |
| Gross Weight | 54 ± 2 Kg |
| Performance : | |
Climatic Type (SN, N, ST, T) | N~ST |
Rated Voltage/ Hz | 220 ~ 240/ 50 |
| Compressor Input Power (Watt) | V 01.01-88 V 01.02-88 |
| Compressor Type | V 01.01-RSCR V 01.02-RSCR |
Cooling Effect | Freezer Cabinet Less than -18℃ Refrigerator Cabinet 0℃ to +5℃ |
| General Features : | |
Temperature Control (Electronic/ Mechanical) | Mechanical |
Defrosting (Automatic/ Manual) | Manual |
Handle (Recessed/ Grip) | Recessed/ Grip |
Lock | Yes |
Refrigerant | R600a |
| Thermostat | RoHS Certified |
Capillary | Copper |
Polyurethane foam blowing agent | Cyclopentene [Eco-friendly (100% CFC & HCFC Free) Green Technology] |
| Recommended voltage stabilizer capacity | V 01.01-Low Voltage(140~260V) For V 01.01 - Wide Voltage Range (140Vac - 260Vac). Voltage stabilizer is not required. In case of voltages beyond this range, 1000VA is recommended. V 01.02-Low Voltage(135~260V) For V01.02 - Wide Voltage Range (135Vac - 260Vac). Voltage stabilizer is not required. In case of voltages beyond this range, 1000VA is recommended. |
| Refrigerator Compartment : | |
Shelf (Material/ No.) | Wire/2 |
Door Basket | GPPS/3 |
Interior Lamp | Yes |
Vegetable Crisper | Yes |
Vegetable Crisper Cover | Yes |
Egg Tray or Pocket | Yes |
| Freezer Compartment : | |
Shelf (Material/ No.) | Wire/2 |
Drawer | HIPS/3 |
| Net Dimensions : | |
Width/mm | 555 mm |
Depth/mm | 630 mm |
Height/mm | 1410 mm |
| Packaging : | |
Width/mm | 580 mm |
Depth/mm | 645 mm |
Height/mm | 1455 mm |
| Loading Capacity- 40HQ/ 40Ft/ 20Ft | 105/ 105/ 52 |
